Patent: 45x Zoom for Waterproof Camera

Patent: 45x Zoom for Waterproof Camera

This patent may show where the next PowerShot D series camera is heading. Below is a patent for a 45x zoom lens that is for a waterproof/dustproof application.

  • Patent Publication No. 2014-109664 (Google Translated)
    • Publication date 2014.6.12
    • Filing date 2012.11.30
    • Related 2014-109665,2014-109666
  • Example 1
    • Zoom ratio 44.41
    • Focal length f = 4.62-13.02-205.00mm
    • Fno. 3.91-6.14-9.00
    • Half angle ω = 36.14-16.58-1.08 °
    • 99.33-103.38-113.64mm overall length of the lens
    • BF 12.11-10.81-4.28mm

Source: [EG]

cr

Patent: Another Multi Layer Related Sensor Patent from Canon

Patent: Another Multi Layer Related Sensor Patent from Canon

Below is another patent for a multi-layer related sensor patent from Canon has come to light. This is the third one that has appeared in the last month or so.

Keith over at Northlight breaks it down in a way that’s easy to understand. “The issue addressed, is light of the ‘wrong’ colour being reflected from one layer into another, which reduces the ability of different layers to respond to photons of only a particular range of colours. This has the potential to greatly improve the colour accuracy and fidelity of such stacked sensor designs.

Patent Publication No. 2014-130890 (Google Translated)

  • Publication date 2014.7.10
  • Filing date 2012.12.28
  • Multilayer sensor drawback of
  • G is light, the image quality is degraded and reflected by the surface of the layer between the G and B layer, re-enters the B layer
  • Canon patents
  • The provision of the dielectric film and the insulating film as an anti-reflection film
  • First insulating layer, B layer, a dielectric film, insulating film, dielectric film, G layer, a dielectric film, insulating film, insulating film, dielectric film, the R layer
  • By increasing the thickness of the dielectric film, to suppress the multiple reflection
  • The dielectric film is between the G layer and B layer, the reflectance with respect to G is lower than B

Source: [EG] via [NL]

cr

Canon Joins Cooperative Agreement to Reduce Patent Trolls

Canon Joins Cooperative Agreement to Reduce Patent Trolls

Asana, Canon, Dropbox, Google, Newegg and SAP Announce Formation of New Cooperative Patent-Licensing Agreement

TOKYO, July 10, 2014—Asana, Canon Inc., Dropbox, Google, Newegg and SAP today announced the formation of the License on Transfer (LOT) Network, a cooperative patent-licensing agreement that will cut down on patent troll litigation and the growing practice of patent privateering.

Patent litigation reached an all-time peak last year, with more than 6,000 lawsuits filed. Most of those suits came from non-practicing entities, also known as patent trolls—companies that don’t have a business outside of licensing and litigating patents.

More than 70 percent of the patents used by trolls come from still-operating companies. Indeed, in a growing trend called privateering, companies are selling patents to trolls that then use those patents to attack other companies. In some cases, those companies arrange to get a cut of revenue generated from the trolls’ suits.

The LOT agreement is a new kind of royalty-free cross-license meant to address these growing systemic problems. Member companies receive a license when the patents are transferred out of the LOT group. That means that companies retain their right to enforce a patent so long as they retain ownership of it. However, as soon as it is sold, a license to the other members becomes effective, protecting them from attacks by the troll to which the patent was sold.

 The agreement includes several other provisions that preserve a patent portfolio’s value, including carve-outs for certain M&A transactions and change of control.

The initial members of the LOT Network range from early-stage startups to established technology companies. Together they own almost 300,000 patent assets, generate more than $117 billion in revenue and employ more than 310,000 people.

“The LOT Network is a sort of arms control for the patent world,” said Allen Lo, deputy general counsel for patents at Google. “By working together, we can cut down on patent litigation, allowing us to focus instead on building great products.”

“Startups need to overcome many risks before they can become mature, thriving companies. The LOT Network is a powerful and creative new idea that will help ensure that patent abuse need not be one of them,” said Dustin Moskovitz, cofounder of teamwork software provider Asana.

“The LOT Network provides a unique mechanism for reducing patent troll threats while maintaining a portfolio’s primary significance and value,” said Kenichi Nagasawa, director and group executive of Canon Inc.’s Corporate Intellectual Property & Legal Headquarters. “Through the further expansion of the LOT Network, I look forward to the patent system restoring its sound functionality.”

“We believe that patents should never be used to stifle innovation,” said Brett Alten, IP counsel at Dropbox, “The LOT network is a creative solution to fight patent abuse that becomes more effective with each company that joins. The more participants there are, the better off we’ll all be.”

“Newegg has a very strong history of successfully battling patent trolls, and the License on Transfer Network is another valuable tool that helps protect participants from frivolous patent litigation,” said Soren Mills, chief marketing officer of Newegg North America. “We’re very happy to join forces with Google and other leading technology companies to preserve the spirit of innovation that’s so vital to our collective well-being.”

“The structure of the LOT Network helps protect innovative patent owners from unwarranted litigation, without stifling valid, beneficial uses of patents, such as cross-licensing,” said Anthony DiBartolomeo, senior vice president and chief IP counsel at SAP. “As long as a company owns their patent they retain all their rights to it.”

Read more at http://www.lotnet.com.

Microsoft and Canon Sign Patent Cross-Licensing Agreement

Microsoft and Canon Sign Patent Cross-Licensing Agreement

REDMOND, Wash., and TOKYO — July 2, 2014 — Microsoft Corp. and Canon Inc. on Wednesday broadened their strategic alliance with the announcement of a broad patent cross-licensing agreement. With this agreement, Microsoft and Canon gain licenses to each other’s highly valued and growing patent portfolios.

“This collaborative approach with Canon allows us to deliver inventive technologies that benefit consumers around the world,” said Nick Psyhogeos, general manager, associate general counsel, IP Licensing of the Innovation and Intellectual Property Group at Microsoft. “Microsoft believes cooperative licensing is an effective way to accelerate innovation while reducing patent disputes.”

This agreement covers a broad range of products and services each company offers, including certain digital imaging and mobile consumer products. Microsoft and Canon have a long history of collaborating to bring high-quality, cutting-edge products to consumers, including color technology. Contents of the agreement will not be disclosed.

“This agreement is a natural extension of our longstanding relationship with Microsoft and commitment to developing innovative technologies,” said Hideki Sanatake, senior general manager, Corporate Intellectual Property & Legal Headquarters of Canon Inc.

Read the full Press Release

cr

Patent: 1.03x Magnification APS-C Viewfinder

As we get closer to the replacement of the EOS 7D, we’re starting to see some patents that will probably point to some features in the upcoming camera. The recent sensor patent is interesting, as well as this viewfinder patent. We had heard previously about the possibility of a 1.15x magnification viewfinder on the next flagship APS-C camera, which would have been equal to the size of a full frame 100% coverage viewfinder.

This viewfinder is slightly larger than the one on the EOS 7D.

A note about the sensor patent, we have heard that Canon is holding back some sensor patents until the camera is announced to the public, as all patent information is public domain. We’ll see if that turns out to be the case.

103viewfinder

Patent Information (Google Translated)

  • Patent Publication No. 2014-115451
    • Publication date 2014.6.26
    • Filing date 2012.12.10
  • Example 9
    • -3 -1 +1 Viewfinder diopter
    • Focal length f = 46.84 48.38 49.99mm
    • Eye point 22.00mm
    • 1.03 1.03 1.02x magnification
    • Pentagonal prism
    • Condenser lens made of glass
    • Eyepiece lens system with the exception of the condenser lens, 4-group structure of the positive and negative positive negative
    • In turn, resin (single-sided aspherical surface), glass, resin (single-sided aspherical surface), the material is glass
  • Patent Publication No. 2014-115452
    • Publication date 2014.6.26
    • Filing date 2012.12.20
  • Example 1
    • -3.00 -1.00 +1.00 Diopter
    • Focal length f = 62.22 59.69 57.39mm
    • Eye Relief 19.9mm
    • Maximum image height 12.4mm
    • Pupil diameter φ15mm
    • Magnification 0.87x
    • Pentagonal mirror

Source: [EG]

cr

Patent: Canon 5 Layer UV, IR, RGB Sensor

A patent showing a 5 layer image sensor from Canon has appeared. UV and IR layers help with color reproduction especially for skin tones.

Keith at Northlight has this to add about the patent: “The pixel structure above, shows a BSI design (back illumination), but obviously no pixel structure. Extending the range of light response to UV and IR would cause issues for current lens designs, but the idea of more than three colour primaries is not new, although it would require a major re-write for support from RAW converter software.”

5-layer

Patent Information (Google Translated)

  • Patent Publication No. 2014-103644
    • Publication date 2014.6.5
    • Filing date 2012.11.22
  • Canon patents
    • I get the visible light
    • I get the ultraviolet light
    • I get the infrared light
    • I want to extract the skin area
    • The skin region of visible light, I will correct the image from the difference of the skin area of ​​ultraviolet light
    • Signal value of the infrared light is regarded as the skin area, the high part

Source: [EG] via [NL]

cr

Patent: Canon EF 400 f/4 DO IS

A patent for a new Canon EF 400 f/4 DO IS has appeared. The current lens has been around since December, 2001 and I think it’s a gem in the Canon lineup.

We’ve seen a lot of DO patents over the years, but no DO lens has been announced since June, 2004 when the EF 70-300 f/4.5-5.6 DO IS came to market.

Canon EF 400 f/4 DO IS

Canon EF 400 f/4 DO IS

  • Patent Publication No. 2014-109700
    • Publication date 2014.6.12
    • Filing date 2012.12.3
  • Example 1
    • Focal length f = 392.00-381.59-332.99mm
    • Fno.
    • Half angle ω = 3.16-3.10-2.81 °
    • Image height Y = 21.64mm
    • The overall length of the lens 292.02mm
    • BF 105.64mm

Source: [EG]Canon EF 400 f/4 DO IS at B&H Photo

Patent: Multi-Lens, Multi-View Camera

Patent: Multi-Lens, Multi-View Camera

Below is a patent for a multi-lens, multi-view camera. I’m not sure what the application would be for such a camera, but I felt the same way about the PowerShot N and it continues to get made. :)

The patents below are translated via Google Translator.

Patent Publication No. 2014-110442

  • Publication date 2014.6.12
  • Filing date 2012.11.30

Canon patents

  • Multi-lens camera concentrically arranged an imaging device and a plurality of lenses
  • I do light field, angle of view changes, perspective changes, noise reduction, resolution conversion, HDR, distance estimation, the disparity estimation

Patent Publication No. 2014-110443

  • Publication date 2014.6.12
  • Filing date 2012.11.30

Canon patents

  • I provided a handle to the multi-lens camera
  • Parameter change in the rotation of the handle

Patent Publication No. 2014-110444

  • Publication date 2014.6.12
  • Filing date 2012.11.30

Canon patents

  • I reduce the number of the imaging lens element than the number of multi-lens camera
  • By the rotation of the optical unit, to select a specific lens

Source: [EG]

cr

Patent: EF 85mm f/1.2L III and Others

Patent: EF 85mm f/1.2L III and Others

A patent showing new 85mm & 50mm designs has surfaced. Both an 85mm f/1.2 and an 85mm f/1.8 appear as well as a 50mm f/1.4 and a 100mm f/2.

An updated 85mm f/1.2L II has been mentioned as being under development for quite some time, and we’re all expecting a new 50mm lens, which is an oft rumored product.

Patent Publication No. 2014-52412

  • Publication date 2014.3.20
  • Filing date 2012.9.5
Example Focal length Fno. Length BF
One 85.00 1.24 125.55 38.98
Two 85.00 1.80 113.57 39.50
Three 51.70 1.41 88.04 39.00
Four 100.00 2.00 120.00 39.60


Image height = 21.64mm

Source: [EG]

cr

Patent: Canon EF 180mm f/3.5L IS

Patent: Canon EF 180mm f/3.5L IS

More Canon lens patents have shown up. This time we get some macro patents that also include hybrid IS. We’ve been told that the 180mm f/3.5L macro is on its way out, and this could be the direction Canon takes it.

A few other focal lengths also appear in the patent as well such as 200mm & 300mm versions with hybrid IS.

The information below is a Google translation.

  • Patent Publication No. 2014-41224
    • Publication date 2014.3.6
    • Filing date 2012.8.22
  • Example 1
    • Zoom ratio 1.37
    • Focal length f = 180.03-167.06-131.08mm
    • Fno (3.6-4.8-5.8 actual aperture). 3.6-3.3-2.59
    • Half angle ω = 6.85-7.38-9.37 °
    • Image height 21.64mm
    • The overall length of the lens 228.39mm
    • BF 68.14mm
  • Example 2
    • Zoom ratio 1.58
    • Focal length f = 198.49-164.7-125.48mm
    • Fno (3.6-4.8-5.8 actual aperture). 3.6-2.99-2.28
    • Half angle ω = 6.22-7.48-9.78 °
    • Image height 21.64mm
    • The overall length of the lens 231.65mm
    • BF 71.4mm
  • Example 3
    • Zoom ratio 1.92
    • Focal length f = 289.97-213.39-151.33mm
    • Fno (3.6-4.8-5.8 actual aperture). 3.6-2.65-2.21
    • Half angle ω = 4.27-5.79-8.14 °
    • Image height 21.64mm
    • The overall length of the lens 294.36mm
    • BF 68.05mm
  • Canon patents
    • Inner focus
    • (Part of the fourth lens group) antivibration
    • Supports Shifutobure (???)
    • Floating

Source: [EG]
