Patent: Canon EF-S 20mm f/2.8 STM

Another lens patent from Canon, this time for an EF-S 20mm f/2.8. Are we going to see a series of inexpensive EF-S primes in the future? This is pretty close to the 24mm f/2.8 STM pancake though.

Patent Publication No. 2015-111192 (Google Translated)

  • Published 2015.6.18
  • Filing date 2013.12.6

Example 3

  • Focal length 20.65mm
  • Fno. 2.88
  • Half angle of view ω = 33.48 °
  • Image height Y = 13.66mm
  • Overall length of the lens 64.00mm
  • BF 35.30mm

Canon patents

  • Negative ShiboTadashi
  • The pay-out the entire
