In this patent application (2025-019790), Canon explores the use of more resin elements to make up some pretty interesting lenses.

We have to preface this by saying that a lot of Canon lenses have resin elements; it is not unheard of, even in the realms of L lenses. Those lenses with BR? That was a resin element. Many of the lenses with molded aspherics also used resin elements as well.

In this patent application, canon is doing something a little different, though; they want to use a large resin element at the business end of the lens, as that typically is the largest and thus heaviest element. However, with temperature changes, the focal position and aberrations can change – so Canon wants to arrange resin elements in a group to cancel out these changes in temperature effects.

Canon RF 24-50mm F2.8

	Wide Angle	Mid Range	Telephoto
Focal Length	24.70	36.56	48.80
F-Number	2.90	2.90	2.90
Half Angle of View	37.93	30.17	23.91
Image Height	19.25	21.25	21.64
Lens Length	127.00	135.58	146.40
Back Focus Distance	19.97	25.52	29.15

Canon RF 24-70mm F2.8

	Wide Angle	Mid Range	Telephoto
Focal Length	24.70	45.00	67.90
F-Number	2.90	2.90	2.90
Half Angle of View	37.63	25.68	17.67
Image Height	19.04	21.64	21.64
Lens Length	141.13	155.45	173.50
Back Focus Distance	13.00	24.93	31.83

Canon RF 28-100mm F4

	Wide Angle	Mid Range	Telephoto
Focal Length	28.84	63.61	101.85
F-Number	4.12	4.12	4.12
Half Angle of View	33.94	18.78	11.99
Image Height	19.41	21.64	21.64
Lens Length	185.56	213.24	248.11
Back Focus Distance	19.76	22.67	23.79

Canon RF 24-35mm F2.0

	Wide Angle	Mid Range	Telephoto
Focal Length	24.70	28.06	33.95
F-Number	2.06	2.06	2.06
Half Angle of View	37.63	35.20	31.36
Image Height	19.04	19.79	20.69
Lens Length	142.44	137.16	130.51
Back Focus Distance	13.00	16.72	18.74

Canon RF 24-35mm F3.5

	Wide Angle	Mid Range	Telephoto
Focal Length	24.70	28.14	33.95
F-Number	3.61	3.61	3.61
Half Angle of View	37.62	35.11	31.76
Image Height	19.04	19.79	21.02
Lens Length	117.52	112.99	107.27
Back Focus Distance	13.12	12.36	12.12
