Patent: Canon RF 50mm f/1.4 USM and other primes

Canon Rumors Guy

Canon EOS 40D
CR Pro
Jul 20, 2010
10,779
3,158
Canada
www.canonrumors.com
A new Canon Japan patent shows the optical formulas for various RF 50mm f/1.4 designs as well as an RF 35mm f/1.4. This patent deals with increasing focusing speed when using lens designs with large diameter elements.
I don’t think any of these optical formulas will become products, so the dream of a new 50mm f/1.4 from Canon probably won’t be coming true any time soon.








RF 50mm f/1.4

RF 50mm f/1.4

RF 50mm f/1.8



Focal length

51.50mm...

Continue reading...

Last edited:
  • Sad
Reactions: 1 users
Nov 2, 2016
849
648
Remember the days when a 50 f1.8-2.0 was a basic Gaussian 6 element design, and the bigger, more expensive f1.4 had 1 more element? The f1.4 also had higher quality. My 50 f1.4 FD was considered to be a superb lens. I suppose today it would fail every test. All of my FD lenses, the pro models, are considered as tiny today.

though my 100mm f2.8 is still one of the sharpest lenses I’ve ever had.

  • Like
Reactions: 1 users
Upvote 0
Nov 2, 2016
849
648
The standards have changed in the past few decades. Technically, sensors have more details than most films, and the standard of living has raised, and people can and do print larger.
Yes, that was the point. My company used to process Kodachrome. We had our own pro process. I used to write for Kodak’s Lab Notes. I’m about as familiar with this as anyone. Kodachrome, according to Kodak, was equivalent to about 14-18MP. So that gives an idea. But that 100 f2.8 is still a very sharp lens. I’ve got an adapter for FD lenses on the EOS mount. Unfortunately, you can’t focus to infinity with it, but otherwise, you can use those lenses. On my 5D mk IV, it’s still pretty damn sharp. Surprising, but true.

  • Like
Reactions: 1 users
Upvote 0

Sporgon

5% of gear used 95% of the time
CR Pro
Nov 11, 2012
4,719
1,537
Yorkshire, England
Kodachrome, according to Kodak, was equivalent to about 14-18MP.
Which Kodachrome ? The only one I have found to come close to 14 mp in resolution and 18mp in colour definition was Kodachrome 25. (35 mil of course).

But I've also found that fine grain 35mm film is as brutal on lenses and technique as a 5DS when you start scanning and outputting to the same kind of sizes we routinely do today.

  • Like
  • Wow
Reactions: 2 users
Upvote 0
Nov 2, 2016
849
648
Which Kodachrome ? The only one I have found to come close to 14 mp in resolution and 18mp in colour definition was Kodachrome 25. (35 mil of course).

But I've also found that fine grain 35mm film is as brutal on lenses and technique as a 5DS when you start scanning and outputting to the same kind of sizes we routinely do today.
K-25.

nah, film is easy, by today’s standards. And by the way, lens manufacturers used to lie all the time about flat field (Leica, I’m looking at you!). Film in film gates where the back plate doesn’t clamp down on the film, isn’t flat. Think about everything that film is and what the requirements for mechanical operation is, and you’ll understand why. It’s a major reason why film lenses can be fairly sharp in the center, and so bad everywhere else, for digital. That’s for lower rez digital. We began, in my lab, to see that for 6MP.

  • Wow
  • Like
Reactions: 1 users
Upvote 0

Del Paso

M3 Singlestroke
CR Pro
Aug 9, 2018
3,295
4,182
K-25.

nah, film is easy, by today’s standards. And by the way, lens manufacturers used to lie all the time about flat field (Leica, I’m looking at you!). Film in film gates where the back plate doesn’t clamp down on the film, isn’t flat. Think about everything that film is and what the requirements for mechanical operation is, and you’ll understand why. It’s a major reason why film lenses can be fairly sharp in the center, and so bad everywhere else, for digital. That’s for lower rez digital. We began, in my lab, to see that for 6MP.
That's exactly what I noticed with an old Leica M Summicron 35 f2 , extremely good on Kodachrome, but marshmallow soft corners on Leica digital bodies under f8. Same applies to the Leica R 28mm f2,8.
Yet, the 50 M, 75 M, 90 M, 135 M and all the other Leica R APO vintage lenses are still tack sharp, even in the extreme corners.
Even most of my Olympus lenses were unusable for digital... and got sold:cry:

Upvote 0

justaCanonuser

Grab your camera, go out and shoot!
Feb 12, 2014
1,026
923
Frankfurt, Germany
I hoped for an EF 50mm f/1.4 IS USM along the lines of the 24-28-35mm trio upgrade since, well, the upgrade. Apparently its not in the cards.
Yeah, I think Canon will not invest in an upgrade of this lens for the EF mount - game over for the medium fast fifty.

Upvote 0
Nov 2, 2016
849
648
That's exactly what I noticed with an old Leica M Summicron 35 f2 , extremely good on Kodachrome, but marshmallow soft corners on Leica digital bodies under f8. Same applies to the Leica R 28mm f2,8.
Yet, the 50 M, 75 M, 90 M, 135 M and all the other Leica R APO vintage lenses are still tack sharp, even in the extreme corners.
Even most of my Olympus lenses were unusable for digital... and got sold:cry:
What’s interesting is how manufacturers handled backfocus. Back then, with manual, analog cameras, there was no backfocus adjustments. A manufacturer decided where to put that main focus at. Sometimes, it was closer to the front, sometimes to the rear. Some lenses were sharper with thinner b/w film, and some with thicker color film. Some were even aimed at thick Kodachrome.

by the way, apochromatic lenses aren’t necessarily sharper, nor do they always have flat field. It just means that three colors focus on the same plain, curved or flat. Stopping down a couple of stops, as always, results in better performance across the frame.

Upvote 0
Nov 2, 2016
849
648
Canon's rangefinder lenses from the 1950s and 60s were even much smaller, my vintage 50mm f/1.8 has about the size of two bottle caps stacked.
Yeah. I used a Nikon rangefinder in college, when I was on the newspaper. Pretty small too. So we’re my Leica lenses for my M5. Though the 90 f2.0 didn’t seem small.

Upvote 0
