Canon RF 2x Extender - anyone used one?

AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
The RF 1.4xTC works well on my 100-500mm and R5 with excellent AF and after some sharpening at 700mm it's pretty close to the RF 800mm in resolution and IQ. I am intrigued as to how well the RF 2x performs in terms of AF and IQ on the 100-500mm in particular. It's so expensive, that it would cost not much more to buy an 800mm RF. But, if the IQ etc are good, it would be tempting to have one in my kit for the occasional 1000mm f/14 shot. I'd be grateful for any first hand experience or for pointers to any reviews (TDP has image quality with it only on the 800mm).

  • Like
Reactions: jprusa

bhf3737

---
CR Pro
Sep 9, 2015
652
1,423
Calgary, Canada
www.flickr.com
I will have RF 2.0xTC this coming weekend on loan and will try it with RF 100-500mm and will post some results here if weather allows. Based on my own experience so far, RF 800 has better IQ that 100-500 + 1.x TC but is less flexible. So I don't expect 100-500 + 2.0xTC to pull a rabbit out of hat, but let's see.

  • Like
Reactions: AlanF

AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
I will have RF 2.0xTC this coming weekend on loan and will try it with RF 100-500mm and will post some results here if weather allows. Based on my own experience so far, RF 800 has better IQ that 100-500 + 1.x TC but is less flexible. So I don't expect 100-500 + 2.0xTC to pull a rabbit out of hat, but let's see.
Thanks and looking forward to your findings. I have done testing of the 800mm vs 100-500mm + 1.4xTC and usern4cr more so. The RF 800 does have the edge but as you say the zoom has the flexibility. I am very tempted by the 800 but having the 100-500 and my style of nature photography being opportunistic I am suppressing the GAS. Judging by my results of the EF 2xTC with the 100-400mm II, I am not hopeful. But as you write, let's see.


Bdbtoys

R5
CR Pro
Jul 16, 2020
372
275
@AlanF Is there something you want to see or have me check in particular?

I have the 100-500, 1.4x, & 2x. I can't directly check against the 600 or 800 because I went with the combo I did for flexibility. Also, I recently used the 100-500+2x (600-1000 effective) while I was at a Blue Angel's practice... which I was fairly happy w/ the results.


AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
@AlanF Is there something you want to see or have me check in particular?

I have the 100-500, 1.4x, & 2x. I can't directly check against the 600 or 800 because I went with the combo I did for flexibility. Also, I recently used the 100-500+2x (600-1000 effective) while I was at a Blue Angel's practice... which I was fairly happy w/ the results.
I am interested in seeing the quality at 1000mm - I'm with you for flexibility, and want to see if it's worthwhile getting the 2x.


Bdbtoys

R5
CR Pro
Jul 16, 2020
372
275
Long - at 700mm and below, the 1.4xTC will be better.

Yes, but's it's nice to know how much IQ you would lose if you dip in the 600-700 range.

Here's the situation I was in... I wanted the variable range, but knew I was mostly going to need the long end, but every once and a while was also going to need the 600.

I semi-decided to do a few at both ends of the range with each configuration to get an overlap. I'll shoot for getting something tomorrow.

  • Like
Reactions: AlanF

AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
Yes, but's it's nice to know how much IQ you would lose if you dip in the 600-700 range.

Here's the situation I was in... I wanted the variable range, but knew I was mostly going to need the long end, but every once and a while was also going to need the 600.

I semi-decided to do a few at both ends of the range with each configuration to get an overlap. I'll shoot for getting something tomorrow.
Thanks, much appreciate.


Bdbtoys

R5
CR Pro
Jul 16, 2020
372
275
TLDR: The TC's are better than cropping.

So did a quick little test w/ no TC, 1.4, & 2.0. I really want to do a better one (not in a semi dark hallway) and with a better test subject (what I thought was a nice piece of paper with black text) ended up being gray-scale text with pixel shading (which I didn't realize until I reviewed the pictures as it was not noticeable looking at it with first glance).

However, I can give a quick summary of what I noticed.

The TC was always better than a crop w/o the TC or a crop on a smaller TC. The detail gained was pretty dramatic.

I would have no issues grabbing the 2.0x over the 1.4x even if I was going to be in the 600-700 range (the overlap of the 1.4 & 2.0) if the 1 stop loss wasn't a factor... the IQ loss at equivalent focal lengths between the 1.4 & 2.0 were negligible.

I'm not happy with this shot, but it was a quick succession of 'something quick' so I could make a reasonable comparison. The ISO was higher than I would have liked (can notice the noise when at 1:1), but it didn't really hinder confirming what I suspected.

What you are seeing is a very small portion of a screen capture of the RAW image w/o any retouching at 100% and 25% scale (I did it this way to show the details and keep the file size super small). It was shot at 1000mm (500+2x), 1/250th, ISO 6400, F14, handheld (and not steady at that). The subject was a cheap paper ruler to measure IPD (text was backwards due to it is meant to be read in a mirror). The large vertical black lines are 1cm apart (so the 100% scale is approx a real life 1cm square). This was shot at a distance of approximately 9 feet. The fact that I could clearly see each printed dot of the grayscale was pretty impressive.


Attachments

  • 2021-05-04_18-59-41.jpg
    369.4 KB · Views: 55
  • 2021-05-04_19-28-07.jpg
    83.8 KB · Views: 51
Last edited:
  • Like
Reactions: AlanF and jprusa

AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
TLDR: The TC's are better than cropping.

So did a quick little test w/ no TC, 1.4, & 2.0. I really want to do a better one (not in a semi dark hallway) and with a better test subject (what I thought was a nice piece of paper with black text) ended up being gray-scale text with pixel shading (which I didn't realize until I reviewed the pictures as it was not noticeable looking at it with first glance).

However, I can give a quick summary of what I noticed.

The TC was always better than a crop w/o the TC or a crop on a smaller TC. The detail gained was pretty dramatic.

I would have no issues grabbing the 2.0x over the 1.4x even if I was going to be in the 600-700 range (the overlap of the 1.4 & 2.0) if the 1 stop loss wasn't a factor... the IQ loss at equivalent focal lengths between the 1.4 & 2.0 were negligible.

I'm not happy with this shot, but it was a quick succession of 'something quick' so I could make a reasonable comparison. The ISO was higher than I would have liked (can notice the noise when at 1:1), but it didn't really hinder confirming what I suspected.

What you are seeing is a very small portion of a screen capture of the RAW image w/o any retouching at 100% and 25% scale (I did it this way to show the details and keep the file size super small). It was shot at 1000mm (500+2x), 1/250th, ISO 6400, F14, handheld (and not steady at that). The subject was a cheap paper ruler to measure IPD (text was backwards due to it is meant to be read in a mirror). The large vertical black lines are 1cm apart (so the 100% scale is approx a real life 1cm square). This was shot at a distance of approximately 9 feet. The fact that I could clearly see each printed dot of the grayscale was pretty impressive.
Thanks for this, I have now ordered one. My old EF 2xTC III and one of my 1.4xTC II are being sold.


bhf3737

---
CR Pro
Sep 9, 2015
652
1,423
Calgary, Canada
www.flickr.com
Here we had snow during Weekend! But today was good weather and I could take a few shots with R5, RF 100-500mm and 2.0x extender. My impression was that for stationary or slow moving objects, the combo works fine, image quality is good, if using some noise removal, but AF was quite sluggish for BIF. With 1.4x extender, the AF has been much better. The advantage of 2.0x was that it could still focus on close subjects. much closer that RF 800mm. The other advantage is that the whole frame can be filled so I ended up with more pixels to work with.
Some sample photos are attached below. I used Topaz Denoise AI for higher ISO files.

A mother goose and her goslings (about 15m away)
20210510 065b.jpg


An American white pelican (about 30m away)
20210510 1296b.jpg


and a porcupine from about 3 meters away.
20210510 2047b.jpg

  • Like
Reactions: AlanF

AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
Here we had snow during Weekend! But today was good weather and I could take a few shots with R5, RF 100-500mm and 2.0x extender. My impression was that for stationary or slow moving objects, the combo works fine, image quality is good, if using some noise removal, but AF was quite sluggish for BIF. With 1.4x extender, the AF has been much better. The advantage of 2.0x was that it could still focus on close subjects. much closer that RF 800mm. The other advantage is that the whole frame can be filled so I ended up with more pixels to work with.
Some sample photos are attached below. I used Topaz Denoise AI for higher ISO files.

A mother goose and her goslings (about 15m away)
View attachment 197542

An American white pelican (about 30m away)
View attachment 197543

and a porcupine from about 3 meters away.
View attachment 197544
Thanks so much for posting these.

  • Like
Reactions: bhf3737

Bdbtoys

R5
CR Pro
Jul 16, 2020
372
275
I have to agree the AF is a bit sluggish (or can miss) more than the 1.4.... however it does make for some very nice pictures (where @bhf3737 stated you have more detail/pixels in the finer points).

I may post the plane pictures from the vacation I mentioned.


AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
My RF 2x Extender arrived lunchtime on a 14-day return basis and I put it through preliminary testing vs the bare RF 100-500mm and with the RF 1.4x extender, and also compared it with previous tests on the 100-400mm II and 400mm DO II. I was pleasantly surprised. At 19m distance from the charts, the RF 2x performs far better on the 100-500mm than does the EF 2xTC on the 100-400mm II. The 100-500mm at 1000mm produced crisp lines, and gave 40% more resolution than the bare lens and about 20% more than the 100-500mm at 700mm. It was just slightly better than the 400mm DO II at 800mm and f/8 and distinctly better than the RF 800mm, and even out resolved the 800mm at 1120mm with a 1.4x extender. At 12m from the charts, where I found the EF 2xTC on the 100-400mm II to be weak, the RF system at 1000mm is excellent. After those tests, I took some shots at the local lake and of a Greenfinch on my feeder. Here are some typical shots, cropped to fit on the site without compression and where 1 px on the crop = 1 px on the original. It focussed fast enough for some BIF. I'm keeping the RF 2x as it will be useful on those occasions where I am really pushed for reach - it won't be on my lens as a matter of routine although it does produce really sharp and contrasty images.



snappy604

EOS RP
CR Pro
Jan 25, 2017
556
433
nice to see some real world shots.. I'm tempted by the 100-500 vs my 150-600 sigma.. . but the extra range has always been a concern. so wondered about the TC and if would be worthwhile... seems like the answer is... yes.


AlanF

Stay at home
CR Pro
Aug 16, 2012
8,290
10,386
I checked out the IS. My criteria are off scale compared with the usual as I count shots as being perfect only when no shake is detected at the pixel level when hand held at 20m from a high resolution target. At this distance, shake is magnified and at closer distances, shake becomes less and less observable. At 1000m, from 1/800 to 1/1600s, 70% were absolutely shake free, and 30% pretty minimal. At 1/500s, 50% perfect, 33% nearly there and 17% bad. At 1/250s, 30% perfect, 30% nearly there and 40% bad. At 1/125s, 17% perfect, 17% nearly there and 66% bad.
These figures are pretty good. In general, I try to keep shutter speeds faster than 1/500s for optimal sharpness. From experience, a setting of 1/1250s, iso 1000 at 1000mm f/14 would be fine for me on a bright day.

  • Like
Reactions: mikekeck
