Astronomers are looking pretty much straight up whenever possible and they still fight "seeing conditions". Thermal distortion is much greater looking horizontally. Shallow angle horizontal views through thermal layers are the worst. The same rule holds for microwave siting. OTOH, just because you have a 5200mm lens doesn't mean you have to use it to photograph something 30 miles away. You can also take photos of the anthill in the neighbor's yard :).
Waiting for the gallery of celebrity nose hair pics.


mdcmdcmdc

7Dii, M5, 100 (film), α6400
CR Pro
Sep 4, 2020
113
144
When were these made? I didn't see a copyright date in the scans. Looks like the kind of thing NASA would have used to follow rocket launches in the 1960's and 1970's. Or other agencies of one or more governments to follow other things.


pape2

EOS 90D
Mar 19, 2021
117
147
s

Astronomers are looking pretty much straight up whenever possible and they still fight "seeing conditions". Thermal distortion is much greater looking horizontally. Shallow angle horizontal views through thermal layers are the worst. The same rule holds for microwave siting. OTOH, just because you have a 5200mm lens doesn't mean you have to use it to photograph something 30 miles away. You can also take photos of the anthill in the neighbor's yard :).
My art landscape pic with RF800mm :) bird looks ok


mdcmdcmdc

7Dii, M5, 100 (film), α6400
CR Pro
Sep 4, 2020
113
144
When were these made? I didn't see a copyright date in the scans. Looks like the kind of thing NASA would have used to follow rocket launches in the 1960's and 1970's. Or other agencies of one or more governments to follow other things.
I did some additional digging courtesy of Google and found this from 2000:


The email reporduced there refers to a booklet dated May 1965, which is consistent with the CR article saying mid-1960's. Judging from the scans, however, it doesn't look like it's the same brochure that was posted on CR. The email above refers to them as "TV" series lenses, and indeed, the label on the 2000 mm f/11 lens in the image says "TV LENS" which is not in the scans posted on CR.

If you follow the "MORE Images..." link at that page, you'll see the 800 and 2000 mm lenses with their hard cases. Looks like they each had *two* hard cases, one for the lens and one for the hood!

I also found a couple of mentions of the 5200 f/14 saying only three were made. Seems plausible but I don't have links.


Dragon

EF 800L
May 29, 2019
498
465
Thermal distortion and mirages. no filters
It is interesting (and informative to understand) how thermal distortion is localized based on terrain and airflow. layering based on elevation is the most common condition, but here you are showing clarity in the foreground with extreme distortion in the background (i.e. horizontal stratification). I am guessing there was breeze between you and the bird that wasn't present in the background. I have an EF 800L that I spend some quality time with and the conditions are ever changing and only rarely excellent. That will be a challenge for users of longer mirror lenses if Canon decided to bring them back. I have found that the mirrors seem to have less useful DOF (possibly because of the Bokeh transition) than a refractor (I also have a Nikon 1000mm Cat). Accurate AF would be a huge help in nailing focus.

Last edited:

pape2

EOS 90D
Mar 19, 2021
117
147
It is interesting (and informative to understand) how thermal distortion is localized based on terrain and airflow. layering based on elevation is the most common condition, but here you are showing clarity in the foreground with extreme distortion in the background (i.e. horizontal stratification). I am guessing there was breeze between you and the bird that wasn't present in the background. I have an EF 800L that I spend some quality time with and the conditions are ever changing and only rarely excellent. That will be a challenge for users of longer mirror lenses if Canon decided to bring them back. I have found that the mirrors seem to have less useful DOF (possibly because of the Bokeh transition) than a refractor (I also have a Nikon 1000mm Cat). Accurate AF would be a huge help in nailing focus.
Lot of distance difference between elements too ,bird maybe 500 meter away. rocky island 1km far and big island horizont maybe 3km away. If i am thinking right islands :p
Could be also 500m ,1,3km and 7km
And it was hot day away from shore was 25c and on shore maybe 15c and there was pack ice more far on sea.

  • Like
Reactions: Dragon

Ruined

EOS R
Aug 22, 2013
930
59
If this happens, I have a feeling this is going to be like the Diffractive Optics lenses where people are like "wow, cool" at first, but over time end up ultimately disliking the tech.


telemaque

Before Sunset
CR Pro
Nov 30, 2019
121
77
$50,000 for a 5200 mm f/14 sounds like a lot of money for an older design. It is in the same league as a modern telescope with similar specs. Here is a 4800 mm f/8

and this Italian company is very known for high quality products. The Ritchey Chretien design gives also less diffraction on the side of the image.

  • Like
Reactions: AJ

justaCanonuser

Grab your camera, go out and shoot!
Feb 12, 2014
841
692
Frankfurt, Germany
s

Astronomers are looking pretty much straight up whenever possible and they still fight "seeing conditions". Thermal distortion is much greater looking horizontally. Shallow angle horizontal views through thermal layers are the worst. The same rule holds for microwave siting. OTOH, just because you have a 5200mm lens doesn't mean you have to use it to photograph something 30 miles away. You can also take photos of the anthill in the neighbor's yard :).
But the anthill must be 100 m away minimum. Btw modern optical telescope for astronomy use adaptive optics to restore light wave fronts distorted by atmospheric blur and get sharp images.


SteveC

R5
CR Pro
Sep 3, 2019
2,409
2,274
But the anthill must be 100 m away minimum. Btw modern optical telescope for astronomy use adaptive optics to restore light wave fronts distorted by atmospheric blur and get sharp images.

Unless something has drastically changed, adaptive optics aren't found (yet) on telescopes for amateur astronomers; we are talking the big ones like the ones on Kilauea that professional astronomers may be lucky enough to get to use.


Dragon

EF 800L
May 29, 2019
498
465
But the anthill must be 100 m away minimum. Btw modern optical telescope for astronomy use adaptive optics to restore light wave fronts distorted by atmospheric blur and get sharp images.

True of the telescopes on top of Mona Kea using lasers to monitor the atmosphere, but not something you will find in a back yard telescope.


mdcmdcmdc

7Dii, M5, 100 (film), α6400
CR Pro
Sep 4, 2020
113
144
There are so-called "adaptive optics" systems marketed for amateurs, but they're not the atmospheric compensation/mirror deforming systems used by the pro observatories. They look like they use moveable optics to rapidly compensate for smaller tracking errors than the normal autoguiding can handle. In that sense, they're more like IS for telescopes.

E.g.:


Dragon

EF 800L
May 29, 2019
498
465
There are so-called "adaptive optics" systems marketed for amateurs, but they're not the atmospheric compensation/mirror deforming systems used by the pro observatories. They look like they use moveable optics to rapidly compensate for smaller tracking errors than the normal autoguiding can handle. In that sense, they're more like IS for telescopes.

E.g.:
Looks like something to stabilize the system for very long exposures by tracking a bright guide star. Probably does more to minimize the effect of stepper motors and wind vibration than to mitigate atmospheric effects, but it could help with the latter in some cases. It would do nothing for a typical 1/100th second (or faster) daylight exposure.
