    Canon patents a built-in tilting viewfinder

    By Updated:31 Comments1 Min Read Canon Patents
    patenttiltevf 728x364 - Canon patents a built-in tilting viewfinder

    Here is an interesting patent from Canon, an EOS R series body with a built-in tilting viewfinder. This would definitely be a feature a lot of people would enjoy using on a camera like the Canon EOS R5 Mark II.

    I have used such a viewfinder with the Leica M11 and I love it. It makes getting lower a heck of a lot quicker and easier.

    The patent shown here is extremely in-depth, so I would wager that we will see this on a Canon camera in the near future.

    patentevftilt01 scaled - Canon patents a built-in tilting viewfinder
    patentevftilt02 scaled - Canon patents a built-in tilting viewfinder
    patentevftilt03 scaled - Canon patents a built-in tilting viewfinder

    You can check out the full patent at JPO here.
