It's not that Canon didn't tell us, it's that Richard didn't pass along the full explanation. He hints at it, though, right at the start: "I had previously discussed these as quarter-wave optical designs...," in reference to the quarter wave plates (QWP) that convert linearly polarized light to circularly polarized light and back.
Details are in the patent, and the light manipulation you're missing is polarization, more than once in the optical path and both linear (POL) and circular (QWP2, QWP1), plus selective reflection/transmission.
View attachment 228270
Thanks, this now makes sense for most items. The items that make my head scratch are:
The sensor only receives horizontal polarization component of the light, so you basically have polarization filter inside your lens which you cannot remove.
But furthermore, switching from linear to circular (or back) should reduce light by 1 stop, so you wouldn't get much light in the end. Counting the light path for conversions: E D B B B
C (HM) probably also cut 1 stop on that first pass but I'm not sure so I'm leaving it out the calculation.
So that's 5 stops (or 6 if count HM) of light right there. Maybe I should go read the patent as this is interesting although I'm not yet sure if it's practical.
Also, QWP are fairly frequency sensitive so I'm wondering how much different the far ends of light spectrum will behave on that.
