UPDATED: Canon EOS 80D Specifications

Canon Rumors Guy

EOS-1D X Mark III
CR Pro
Jul 20, 2010
8,952
1,695
Canada
www.canonrumors.com
HTML:
The specifications for the Canon EOS 80D have leaked ahead of the official announcement, which is expected soon.</p>
<p>Updated Specifications from the same source:</p>
<ul>
<li><span class="notranslate">New 24.2MP APS-C CMOS sensor.</span> <span class="notranslate">Adopt a new miniaturization process</span></li>
<li><span class="notranslate">Dual Pixel CMOS AF</span></li>
<li><span class="notranslate">Image processing engine DIGIC6</span></li>
<li><span class="notranslate">Regular sensitivity ISO100-16000 (extension 25600)</span></li>
<li><span class="notranslate">7560 pixel RGB + IR photometry sensor</span></li>
<li><span class="notranslate">AF 45 points (all points cross type).</span> <span class="notranslate">AF distance measuring point of maximum 27 points F8</span></li>
<li><span class="notranslate">-3EV AF</span></li>
<li><span class="notranslate">Four of the AF area selection modes, including a new “L zone AF”</span></li>
<li><span class="notranslate">Continuous shooting 7 frames / sec.</span> <span class="notranslate">3 frames / second at the silent continuous shooting mode</span></li>
<li><span class="notranslate">The number of pictures 77 copies in JPEG.</span> <span class="notranslate">20 sheets in RAW</span></li>
<li><span class="notranslate">Continuous shooting in live view mode 5 frames / sec. (AF tracking)</span></li>
<li><span class="notranslate">New mirror vibration control system to keep the mirror shock (MVCS)</span></li>
<li><span class="notranslate">Finder is 100% field of view, magnification 0.95 times</span></li>
<li><span class="notranslate">Shutter 30 seconds -1/8000 seconds.</span> <span class="notranslate">Synchro 1/250 sec</span></li>
<li><span class="notranslate">3 inches 1.04 million dot Vari-angle LCD monitor</span></li>
<li><span class="notranslate">Built-in flash (guide number 12)</span></li>
<li><span class="notranslate">Electronic Level</span></li>
<li><span class="notranslate">A new Picture Style “fine detail”</span></li>
<li><span class="notranslate">10 kinds of scene mode</span></li>
<li><span class="notranslate">Anti-flicker</span></li>
<li><span class="notranslate">Video is full HD 60fps.</span> <span class="notranslate">AF tracking</span></li>
<li><span class="notranslate">HDR movie</span></li>
<li><span class="notranslate">Time-lapse movie</span></li>
<li><span class="notranslate">Five types of movies Creative Filters</span></li>
<li><span class="notranslate">Wi-Fi, NFC.</span> <span class="notranslate">Remote shooting</span></li>
<li><span class="notranslate">Media SD / SDHC / SDXC (UHS-I compatible)</span></li>
<li><span class="notranslate">Durability of the shutter is 100,000 times</span></li>
<li><span class="notranslate">USB terminal, HDMI terminal, microphone jack, headphone jack, remote control terminal</span></li>
<li><span class="notranslate">Improved dust and water</span></li>
<li><span class="notranslate">The battery LP-E6N / LP-E6</span></li>
<li><span class="notranslate">Start-up time is 0.16 seconds</span></li>
<li><span class="notranslate">EF-S18-135mm F3.5-5.6 enables remote shooting using the power zoom function in combination with IS USM and the power zoom adapter PZ-E1</span></li>
<li><span class="notranslate">The size of 139.0 x 105.2 x 78.5mm</span></li>
<li><span class="notranslate">Weight 730g (650g body only)</span></li>
</ul>
<p>Canon  EOS 80D Specifications:</p>
<ul>
<li>24.2mp APS-C</li>
<li>Dual Pixel AF</li>
<li>7fps Shooting in live view</li>
<li>5fps in AIS</li>
<li>45 AF Points ( All Crosstype)</li>
<li>ISO 100-16000</li>
<li>Anti-Flicker</li>
<li>100% Viewfinder</li>
<li>3″ Vari-Angle LCD</li>
<li>Touchscreen</li>
<li>FullHD at 60fps Video</li>
<li>Time-Lapse</li>
<li>HDR</li>
<li>Creative Filters</li>
<li>Wifi</li>
<li>NFC</li>
<li>Remote hooting with smartphone</li>
</ul>

		<style type='text/css'>
			#gallery-1 {
				margin: auto;
			}
			#gallery-1 .gallery-item {
				float: left;
				margin-top: 10px;
				text-align: center;
				width: 33%;
			}
			#gallery-1 img {
				border: 2px solid #cfcfcf;
			}
			#gallery-1 .gallery-caption {
				margin-left: 0;
			}
			/* see gallery_shortcode() in wp-includes/media.php */
		</style>
		<div id='gallery-1' class='gallery galleryid-24675 gallery-columns-3 gallery-size-thumbnail'><dl class='gallery-item'>
			<dt class='gallery-icon landscape'>
				<a href='http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_b001.jpg'><img width="168" height="168" src="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_b001-168x168.jpg" class="attachment-thumbnail size-thumbnail" alt="canon_eos80D_b001" srcset="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_b001-168x168.jpg 168w, http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_b001-144x144.jpg 144w" sizes="(max-width: 168px) 100vw, 168px" /></a>
			</dt></dl><dl class='gallery-item'>
			<dt class='gallery-icon landscape'>
				<a href='http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_f001.jpg'><img width="168" height="168" src="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_f001-168x168.jpg" class="attachment-thumbnail size-thumbnail" alt="canon_eos80D_f001" srcset="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_f001-168x168.jpg 168w, http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_f001-144x144.jpg 144w" sizes="(max-width: 168px) 100vw, 168px" /></a>
			</dt></dl><dl class='gallery-item'>
			<dt class='gallery-icon landscape'>
				<a href='http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_t001.jpg'><img width="168" height="168" src="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_t001-168x168.jpg" class="attachment-thumbnail size-thumbnail" alt="canon_eos80D_t001" srcset="http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_t001-168x168.jpg 168w, http://www.canonrumors.com/wp-content/uploads/2016/02/canon_eos80D_t001-144x144.jpg 144w" sizes="(max-width: 168px) 100vw, 168px" /></a>
			</dt></dl><br style="clear: both" />
		</div>

<span id="pty_trigger"></span>


Marauder

EOS RP
Dec 15, 2013
297
0
Re: Canon EOS 80D Specifications

Looks pretty cool! I wonder if the 45 pt AF system will be similar in it's shape to the classic 45 pt system of the pre 1DX 1D and 1DS cameras, or more like a smaller version of the 7D2's pattern. Looking forward to more information.

Oh wait. This was a positive post about a new Canon product and that's out of fashion. Hmm...let me rethink this:

C'mon Canon, why can't you....er.....sorry...got nothing... :eek:


Chaitanya

EOS R
Jun 27, 2013
1,381
539
35
Pune
Re: Canon EOS 80D Specifications

In a few months time Nikon will launch replacement for their D7200 which be better than 80D making Canon look like a *********.


pwp

EOS R6
Oct 25, 2010
2,530
23
Re: Canon EOS 80D Specifications

I'm especially looking forward to the remote hooting. This is a top feature. ;D

-pw


neuroanatomist

I post too Much on Here!!
CR Pro
Jul 21, 2010
24,723
2,311
Re: Canon EOS 80D Specifications

Canon Rumors said:
Remote hooting with smartphone

Hey, that's cool - my iPhone can already hoot thanks to the Sibley's Birds app, but not remotely. ;D


HaroldC3

EOS 90D
Jul 6, 2014
120
42
Re: Canon EOS 80D Specifications

A D7200 with a Canon logo on it. At least it has touchscreen.


PureClassA

Canon since age 5. The A1
CR Pro
Aug 15, 2014
2,119
816
Mandeville, LA
Shields-Photography.com
Re: Canon EOS 80D Specifications

PhotographyFirst said:
da_guy2 said:
So what's the big upgrade over the 70D?
10

;)

Given Canon's now proven commitment for a new sensor fab process, the 80D may arrive as the first crop body with the new on sensor ADC. Could be a major shift for Canon. That type of fab process isnt something you just build for one model.


m8547

EOS M6 Mark II
Dec 19, 2012
70
0
Re: Canon EOS 80D Specifications

Remote hooting?


Attachments

  • owl-img.jpeg
    59.6 KB · Views: 290
Jan 30, 2015
336
0
Re: Canon EOS 80D Specifications

PureClassA said:
PhotographyFirst said:
da_guy2 said:
So what's the big upgrade over the 70D?
10

;)

Given Canon's now proven commitment for a new sensor fab process, the 80D may arrive as the first crop body with the new on sensor ADC. Could be a major shift for Canon. That type of fab process isnt something you just build for one model.
Yes that will be very interesting to see how it plays out with the new sensor tech. Does Canon think better sensors are only for people willing to pay $6,000, or do all of us get it?

45 AF points, 100% viewfinder, and anti-flicker seem like nice gains. Too bad Canon seems to have dropped the ball and did not offer dual card slots like the D7200. I would love to have an 80D with dual slots, so I never have to carry extra cards or a card case ever again. Just two 128 GB cards with backups being written, and I am golden! :)


9VIII

EOS 5D Mark IV
Feb 8, 2013
1,843
0
Re: Canon EOS 80D Specifications

The ISO boost seems moderate, but that's also with a resolution boost at the same time, and if the readout is a lot cleaner than previous bodies then practically speaking you would get more than an extra stop of usable low light performance.


mclaren777

EOS RP
Apr 9, 2012
228
138
Re: Canon EOS 80D Specifications

PureClassA said:
Given Canon's now proven commitment for a new sensor fab process, the 80D may arrive as the first crop body with the new on sensor ADC. Could be a major shift for Canon. That type of fab process isnt something you just build for one model.

I think it's highly unlikely that this sensor has the new ADC technology.

It's almost surely going to be the same disappointing sensor that's in the T6s. :(
